Model
|
BSE8KLNA
|
|
|
Efficiency
|
||
|
Max Efficiency
|
>=98.2%
|
|
|
CEC Efficiency
|
>=97.2%
|
|
|
On Grid AC Output
|
||
|
Rate AC Output Power
|
8KVA
|
|
|
AC Output Voltage
|
120/240Vac(split phase), 208Vac(2/3 phase),230Vac(single phase)
|
|
|
AC Output Frenquecny
|
50/60HZ
|
|
|
Grid Type
|
Split phase,2/3 phase,Single Phase
|
|
|
Max Output Current
|
38.3A
|
|
|
AC Reverse Charging
|
Yes
|
|
|
PF
|
0.8leading. 0.8lagging
|
|
|
Output TH DI
|
< 2%
|
|
|
Back-up AC Output
|
||
|
Rated Backup Output Power
|
8KVA
|
|
|
Max Backup Output Power
|
10kVA 60S. 12KVA 1S
|
|
|
Backup AC Output Voltage
|
120/240Vac(split phase), 208Vac(2/3 phase),230Vac(single phase)
|
|
|
AC Frenquency
|
50/60HZ
|
|
|
Output TH DI
|
<2%
|
|
|
PV Input
|
||
|
PV input power
|
12KW
|
|
|
MPPT number
|
4
|
|
|
PV voltage range
|
350V/85V – 500V
|
|
|
MPPT voltage range
|
120V-500V
|
|
|
Single MPPT input current
|
12A
|
|
|
Battery
|
||
|
Max charging/discharging current
|
190A/190A
|
|
|
Battery Voltage range
|
48V
|
|
|
Battery Type
|
Lithium-ion,Lead-acid
|
|
|
General Data
|
||
|
Operation Temperature range
|
-25~ +60°C
|
|
|
Environment humidity
|
0-95%
|
|
|
Altitude
|
0-4000M (over 2000M derating)
|
|
|
IP rank
|
IP65/NEMA 3R
|
|
|
Weight
|
32kg
|
|
|
Dimension(W*H*D) (mm)
|
530x 660 x 200
|
|
|
Cooling
|
Fan Cooling
|
|
|
Noise(dB)
|
<29dB
|
|
|
Display
|
LCD
|
|
|
Communication
|
Modbus, RS485, WIFI,4G
|
|
|
Safty
|
EN61000-6-1, EN61000-6-3, FCC 15 class B
|
|
|
EMC
|
IEC62109-1, IEC62109-2
|
|
